| Processor | CPU | OPS-PM10C-5205U , Integrated 10th gen Intel® Celeron® 5205U Processor dual cores 2 threads 1.9Ghz processor
OPS-PM10C-I3 , Integrated 10th gen Intel® Core™ Comet Lake i3-10110U 2 cores 4 threads 2.1~4.1Ghz OPS-PM10C-I5 , Integrated 10th gen Intel® Core™ Comet Lake i5-10210U 4 cores 8 threads 1.6~4.2Ghz OPS-PM10C-I7 , Integrated 10th gen Intel® Core™ Comet Lake i7-10510U 4 cores 8 threads 1.8~4.9Ghz |
| CPU package | BGA |
| chipset | Support Comet Lake-U Serial processor |
| BIOS | EFI BIOS |
| Memory | Technology Architecture | Single channel DDR4 2133/2400/2666MHz |
| socket | 1*DDR4 SODIMM 260 Socket |
| Video | Graphic controller | Intel UHD Graphics 620 ；graphics models related to CPU |
| MINI DP | MINI DP support max resolution 4096x2304 60HZ |
| HDMI | support max resolution(HDMI2.0)4096*2304@60HZ Support 4K display output |
| Dual display | HDMI+MINI DP sync or asynchronous display |
| I/O back panel | Port | 1*MINI DP,1*HDMI,1*LAN,2*USB3.1( GEN2),2*USB2.0,1*MIC-OUT/LINE-OUT,1*1*Power indicator, 1* hard disk indicator,1*switch button, |
| 1*1*TYPE-C(USB3.1 GEN2 TYPE-C interface only supports data transmission) |
| Internet | controller | 1*Intel I219-LM Gigabit Ethernet, RJ45 interface |
| Audio | controller | Realtek HD ALC662 audio decoding (left and right channel + microphone) |
| Super I/O | controller | IT8163E |
| Hardware control | Watchdog timer | 0-255 seconds to provide watchdog routines |
| Cooler | Aluminum fan heatsink |
| Input / output interface | USB | 2*USB3.1( GEN2)
2*USB2.0 |
| Com port | 1*RS-232 |
| Expansion bus | NGFF | 1*NGFF port(KEY E) |
| NGFF | 1*NGFF port support 3G/4G module |
| storage | SATA | 1*standard SATAIII port,maximum transfer rate of 6Gb/s( with SATA_HDD choose one,default is SATA_HDD) |
| SATA_HDD | 1*SATA_HDD hard disk interface,maximum transfer rate of 6Gb/s(with SATA choose one) |
| NGFF | 1*NGFF_SSD port |
| Power type | Power type | Single input DC power supply,DC12-19V,+/-5% |
| Working temperature | Working temperature | -20℃ ~ +60℃ |
| Storage temperature | -40℃ ~ +85℃ |
| Operating humidity | 0% ~ 90% relative humidity, no condensation |
| Storage humidity | 0% ~ 90% relative humidity, no condensation |
| System | | WIN10 Linux |
| Size | Size | 165*114.2 mm |
| Weight | 0.5KG |
| System | | Windows10 Linux |
| Size | Size | 165*114.2mm |
| Weight | 0.5KG |
